48 Well Real Time PCR Machine

    ModelGentier48E
    Thermal block
    Sample capacity(wells)48
    Reaction volume5-100ul
    Consumables0.2ml 8-strip tubes,0.2ml  PCR single tube(Optical flat cap. Clear tube)
    Temperature range0℃-100℃
    Heating/cooling systemPeltier
    Max heating rate8.0℃/sec
    Average heating rate6.0℃/sec
    Max cooling rate5.5℃/sec
    Average cooling rate4.0℃/sec
    Temperature accuracy±0.1℃
    Temperature uniformity±0.1℃
    Gradient range1℃-40℃
    Gradient block8row
    Special temperature protocolGradient PCR, Long PCR, Touch Down PCR
    Heat Lid
    Temperature rangeRoom temperature-110℃
    Optical system
    Excitation Source4LEDs
    DetectorPhotodiode
    Detection positionExcitation and scan from lateral
    Detection method4 channels scanning at the same time, no edge effect
    Detection time2 seconds for 48 wells for all channels
    Range of excitation/emission wavelengths(nm)1. 465/510(FAM,SYBR Green I,SYTO9,Eva
    Green,LC Green)
    2. 527/563(HEX,VIC,TET,JOE)
    3. 580/616(ROX,Texas Red)
    4. 632/664(Cy5)
    Probe                     Taqman Probe,Molecular beacons probe,
    scorpion probe
    MultiplexingUp to 4 targets
    Fluorescence Linearityr≥0.990
    Fluorescence Dynamic RangeAdjustable
    Performance
    Sample Linearity/r/≥0.999
    Sample repeatabilityCt value CV≤0.5%
    Sample dynamic Range1-1010   copies
    Software Functions
    Data Analysis ModesQualitative analysis, Absolute quantification, Relative quantification, Genotyping
    analysis, Endpoint analysis, Melt curve analysis, High Resolution Melting
    Control Modes7touch screen
    2. PC direct control
    3.WLAN control(one PC can control max 10 unis, and device can be controlled by any PC in the WLAN)
    Data StorageUpload and download through USB disk, 1000 results can be stored in machine
    Power failure protectionAutomaticly start running experiments after power supply, no need wait PC software
    Customize ReportTempletes reserved, report can customized
    Administration ManagementAdministratior can set functions limits for users
    Fault ManagementFault report and analysis,solution instruction
    LIS connectionCSV,Excel,TXT format data output, open port for LIS connection
    Others
    PC operating systemWin7, Win 10
    Communication Port1 ethernet and 2 USB
    Foot print(WxDxH)260mmX400mmX260mm
    Weight11kg
    Power usageAC100 to 125V/200to 240V(50/60HZ)
    Power consumption600VA
    Work environmentTemperature:10℃~30℃ Humidity:20%~85%
